    Standard hydraulic pipe clamps with polyamide pipe clamp body,galvanized steel plates&bolt

    Ask Lasest Price
    Brand Name : YMP
    Certification : ISO 9001
    Model Number : YMPLNG3
    Delivery Time : 7 days
    Payment Terms : T/T
    Supply Ability : 100000 pieces per week
    • Product Details
    • Company Profile

    Standard hydraulic pipe clamps with polyamide pipe clamp body,galvanized steel plates&bolt

    1) Size range:
    fit for tube / pipe size O.D. 6mm -102mm
    2) Structure:
    Assembly including cover plate, welded plate (elongated plate available), clamp bodies (2), high strength bolts (2).
    Rail clamps (L-G9 series) available: cover plate + clamp body(2)+ bolts(2) + rail nuts(2), installed on steel channels or rails.
    Stackalbe Clamps (L-G13) available (max. 5 layers): Stackable Bolts + Clamp body + safety locking plates.
    3) Materials:
    Cover Plate: Galvanized Carbon steel(mild steel)
    Welded Plate: Galvanized Carbon steel
    Bolts: Galvanized carbon steel
    Clamp Body: Polypropylene(PP)
    Excellent UV, weathering and chemical resistance – even under extreme conditions.
    4) Working Temperature:
    PA -30 centi degree up to +90 centi degree in dark green colour
    5) Application:
    This product is suitable for oil, liquid and gas pipe /tube installation and fastening in the hydraulic system in different areas such as the metallurgy, construction machinery, petroleum industry, chemical industry, ship buliding, power station and so on.
